Step-Up Ring Helps

I really like my Pentax K20 digital camera with the Pentax 18 to 250 mm telephoto zoom lens.   I often use a polarizing lens to help make skies bluer.  When I use the polarizing lens, with the 18 to 250 mm lens I see vignettes in all four corners of my picture.  I’m guessing that this is because the 18 mm setting for the lens “sees” at a wide angle consequently catches the edges of the polarizing lens and that’s what appears in photos.  Here’s an example of what I mean:

Notice the darkened corners. This is know as a vignette.

Step-up rings provide a way to fit a larger diameter filter or accessory onto a smaller lens. The step-up ring screws onto the lenses threading and provides a larger thread which the photographer can then attach other elements including a polarizing filter or more step-up rings.

In my case, my lens has a 62 mm diameter.  I purchased a 62 mm to 72 mm step-up ring.  I also purchased a new 72 mm polarizing filter to screw it into the front of the step-up ring.  It worked great.

No vignette using the step up ring.

The step up ring gave enough diameter space so that the 18 mm wide angle setting did not “see” the edges of the polarizing lens and the vignettes did not appear.

This entry was posted in Uncategorized. Bookmark the permalink.

4 Responses to Step-Up Ring Helps

  1. Wonderful pictures. I will first focus on getting a halfway decent camera – then worry about set up rings. 🙂 I remember you telling me about those last summer.

  2. You are right. Get a good camera then worry about other little things to get.

  3. Ram says:

    I recently bought a Digital Visions 0.5x wide angle lens for my Sony DSC H2. I am experiencing vignettes similar to the one above. So is polarizing filters is the solution to remove the vignettes?
